How To Install Internal Bifold Doors On Laminate Flooring

How to Install Bifold Doors on Laminate Flooring

Internal bifold doors are fairly easy to install but one of the most common concerns people have when considering whether to fit the doors themselves is the effect it will have on their laminate flooring. Many people assume that they will have to take up the entire laminate but this is not the case, interior bifold doors can be installed using a simple two hole system.

Home
›
Bifold Doors
›
Internal Bifold Doors
›
How to Install Bifold Doors on Laminate Flooring

What Tools You Need:

Pencil
Drill
¼” drill bit for wooden subfloors or 3/8” drill bit for concrete subfloors
5/8” drill bit
Metal washers
Masking tape
Another person to help you attach the door would be useful

How To Install Trackless Bifold Doors On Laminate Flooring

The first thing you will need to do is put masking tape on your laminate flooring around where you will be installing the doors. This will protect your flooring while you drill the holes for the bracket. The tape will also be easier to draw on than your floor.
Once the tape is down you will need to position the bottom bracket next to the door jamb, in the centre. Use your pencil to mark a hole for the screw – this will be the hole that holds your floor to the ground.
Take the smaller drill bit (base the size on the material of your subfloor) and drill a hole where your pencil mark is. The hole you drill needs to be about an inch wide and will need to go through the laminate and into the subfloor. You can check the size of the hole by putting a plastic screw in the hole.
Next you need to drill a second hole. Use your 5/8” drill bit as this needs to be wider. This hole should only go through your laminate and it will help ensure your floating doors can move as they should.
Put a metal washer over the hole in the subfloor. Check beforehand that your screw can go through the washer. Load a few more washers on top of the hole in the subfloor until they come sit ¼ of an inch on top of your laminate flooring. You need to reposition the bracket on top of the washers and put the screw through the hole in the bracket down into the subfloor.
You will then need to screw another hole into the jamb to hold the bracket to the door frame.
Once this is done you can remove any masking tape you put down at the beginning.

How To Add Tracking To Your Internal Bifold Doors

You will now need to add the tracking for the doors. You will be adding this to the top of the doorframe so you need to put the tracking in position. Use your pencil to mark where you will be adding the screws and drill the holes as needed. When you’ve done that, screw the track onto the door frame.

If you look at the installation kit that came with the doors you should find three pins. You are now going to put the pins into the door. The first pin you should find is a smooth pin, the door should already have holes in so it should be a case of inserting this into the hole at the top, on the side where the hinge is. You should then have a roller pin, the one with the nylon cap on top. Put this in the other hole on the top of the door.

Make sure this goes all the way in, if you’re struggling you could use a hammer but be very careful and only tap it lightly. You should have one final pin which is meta with ridges on. You want to put this pin on the same side as the smooth metal pin but on the bottom of the door. Once all the pins are in, you can put the door in place. This is where another person might prove useful. Insert the pins at the top of the door into the tracking first and then connect your ridged pin into the bottom bracket.

Once that’s all done, you should be all set. You can now enjoy your new bifold doors.

We also have a helpful guide to installing bi-fold doors on carpeted flooring so you can fit bifold doors anywhere in your home.

Check out our full range of internal bifold doors here and if you have any questions, get in touch with a member of our friendly customer service team.

In Summary

If you want to find out how to install bifold doors on carpet flooring, we've put together a little guide for that for that too.

Check out our full range of bifold doors on our website. With lines of internal French doors and French folding doors to boot, there's plenty of options available that will lighten up the interior of your home. Head over to our FAQs section if you have any questions, they may have already been answered. If you have patio doors in mind, we also have a line of external bifold doors on our website that can really transform a space.

Additional Information

Heritage Doors, Floors and Windows: Creating a Modern Heritage Style Look

Find out more about heritage style doors, windows and flooring. We'll discuss the modern heritage look and how to achieve it.

Can Fire Doors Be Propped Open?

Unsure about the legal ramifications of wedging a fire door open? Here we look at why it's always best to keep fire doors closed and how they help protect your property and those in it.

Where are Fire Doors Required?

Unsure whether you need a fire door? Here we look at where you'll need to install one and how you can check if your current internal doors are fire doors.

What Are Fire Doors?

Unsure what fire doors are or why might need them? Here we answer your fire-rated door related questions with our helpful guide.

Style Tips: Choosing Internal Door Handles

Ready to choose new internal door handles? Unsure whether to go for traditional or modern handles? Check out our style tips to help you decide.

Can you drill holes in laminate flooring?

Yes you can drill holes in laminate flooring. If you choose an internal bifold door system with a bottom track such as those in the Roomfold Deluxe range, to install the doors you will need to cut your laminate flooring to sink the track that holds the bottom of the door panels. This is needed to keep your doors stable. Likewise, you'll need to install drop bolts that allow you to secure the door. If you use a sharp, strong drillbit it should not be hard to get a drill through laminate flooring - just take the job slow and steady to avoid splitting the laminate.

Does an internal bifold door need a bottom track on a laminate floor?

When it comes to internal bifold doors, you don’t have to have a bottom track at all and there are plenty of ranges out there that are exclusively top-hung such as the Roomfold Grande range. This makes life a lot easier when installing internal bifold doors in a room with laminate flooring, as you don’t need to worry about fixing it to the flooring and splitting your laminate. You can hang your internal from a top track instead, as internal bifolds are rarely heavy enough to need a top and bottom track.

Can an internal bifold door be hung on hinges?

Bifold doors will always need a certain number of hinges to connect the panels to each other. However, they don’t bear the weight of the door in the same way that they would for a traditional single leaf door. The weight of the panels is shared between the side of the door frame and the track they run along.

How do you transition a floor under an internal bifold door?

When you use internal bifold doors, you should not necessarily need to set a specific transition. Unlike external bifold doors, you don’t need to worry about threshold height and weatherproofing which makes it a lot easier. One of the benefits of interior bifold doors is being able to make two separate spaces feel like one room. This is best achieved by using the same flooring in both rooms, and just continuing them uninterrupted beneath the door.
